Wide Applicability▼
Ideal for automated feeding and boxing of diverse products, including:
-Food & Pharmaceuticals
-Daily Chemicals & Cosmetics
-Stationery & Hardware
-Entertainment Products
Smart Features▼
• Flexible Adjustment: User-friendly HMI allows customizable box-count settings.
• End-to-End Automation:
Online material detection
Batch number stamping
Flap sealing (compatible with hot-melt adhesive)
Defective material rejection
Finished product output
Precision & Efficiency
Streamline your production with seamless automation and minimal manual intervention.
Technical Parameter▼
Speed 30-120 carton/min | ||
Carton | Quality request | 250-350g/㎡（depends on carton size) |
Dimension range（L×W×H） | L(70-200)mm*W(35-120)mm*H(14-70)mm | |
Air compression | Working pressure | ≥0.6mpa |
Air consumption | 120-160L/min | |
Power supply | 220V /380V 50HZ | |
Power | 1.5kw | |
Machine dimension（L×W×H） | 3220㎜×1210㎜×1770㎜ | |
Weight | 2000kg | |
